Cement Mill Introduction:
The cement mill is mainly used in grinding the raw materials and end products in cement plant. It is also suitable for various ores and other materials metallurgy, mine, chemical and construction. Besides, it has two forms of milling, one is an open form, and another is a recycle close form equipped with powder concentrator. It is widely applied in many industries and has simple operation.
It has many advantages such as, strong adaptability, continuous production, large crushing ratio, easy to adjust the size of the products. And it is suitable for both dry production and wet production, also can allow the milling and drying processing simultaneously.
Description
| Name: | Coal Mill Machine | Loading Weight (ton/time): | 0.05-15 |
|---|---|---|---|
| Yield(t/h): | 2-38 | Control System: | PLC Computer |
| Weight: | 17-175 | Loading Capacity(t/h): | 6.2-80 |
| High Light: | 60t/h Cement Mill Machine,Coal Cement Ball Mill,60t/h Cement Ball Mill | ||
Main Technical Parameters
| Spec. (m) | Rotary speed(r/min) | Feed size (mm) | Capacity(t/h) | Load of grinding media (t) | Main motor | Main reducer | Weight (exclude motor and reducer)(t) | |||
| Model | Power(kw) | Speed (r.p.m) | Model | Speed ratio | ||||||
| 2.2×11 | 22.2 | ≤25 | 15~17 | 50 | JR1512-8 | 570 | 740 | ZD80 | 5 | 83 |
| 2.4×8 | 20.91 | ≤25 | 14~18 | 39.5~42 | JRQ1512-8 | 570 | 740 | ZD80 | 5 | 76.4 |
| 2.4×9 | 20.91 | ≤25 | 23~25(close) | 50 | TR1512-8 | 570 | 740 | ZD80 | 5 | 81 |
| 2.4×10 | 20.91 | ≤25 | 16~18(open) | 50 | TR1512-8 | 630 | 740 | ZD80 | 5 | 92.4 |
| 2.4×11 | 21 | ≤25 | 17~19(open) 20~22(close) | 60~62 | YR710-8/1180 | 710 | 740 | JDX630 | 5.6 | 105 |
| 2.4×13 | 21 | ≤25 | 21~22(open) 24~26(close) | 66~68 | YR800-8/1180 | 800 | 740 | MBY710 | 6.3 | 117 |
| 2.6×10 | 20.6 | ≤25 | 21~24 | 64 | YR800-8/1180 | 800 | 740 | JDX710 | 6.3 | 133 |
| 2.6×13 | 20.6 | ≤25 | 28~31 | 80 | YR1000-8/1180 | 1000 | 740 | JDX800 | 6.3 | 151 |
| 3.0×9 | 19.13 | ≤25 | 35~40(close) | 80~83 | YR1000-8/1180 | 1000 | 740 | MBY800 | 7.1 | 137 |
| 3×11 | 18.92 | ≤25 | 44~47(close) | 95~100 | YR1250-8/1430 | 1250 | 740 | JDX900 | 7.1 | 159 |
| 3×13 | 18.92 | ≤25 | 39~45(open) | 110~116 | YR1400-8/1430 | 1400 | 740 | JDX900 | 7.1 | 183 |
| 3.2×11 | 18.3 | ≤25 | 45~48(close) | 110~112 | YR1400-8/1430 | 1400 | 740 | JDX900 | 7.1 | 195.5 |
| 3.2×13 | 18.7 | ≤25 | 45~55(open) | 125 | YR1600-8/1430 | 1600 | 740 | JDX1000 | 7.15 | 213 |
| 3.5×13 | 17.5 | ≤25 | 50~60 | 150 | YR2000-8/1730 | 2000 | 740 | JDSX1000 | 6.3 | 240.5 |
| 3.8×13 | 16.3 | ≤25 | 65~70 | 185 | YR2500-8/1730 | 2500 | 740 | JS130-C-F1 | 220 | |
| 4×13 | 16.3 | ≤2 | 78~80 | 191 | YRKK900 | 2800 | 745 | JS140-A | 200 | |
