Jaw crusher also known as tiger mouth, is one of the commonly used crushing equipment in sand and gravel production lines. There are many different types, such as coarse crushing series and fine crushing series, each series is divided into different types. Model specifications, so when purchasing equipment, users should choose a suitable model according to the actual situation, so as to avoid unnecessary trouble for later use. So what is the output of jaw crusher per hour? What are the commonly used model specifications?

1. Introduction of commonly used jaw crusher models

1. Coarse crushing series

(1) PE-600×900 type: the feeding particle size is 500mm, the adjustment range of the discharge port is 65-160mm, the power is 55-75kw, and the output per hour is 50-160t;

(2) PE-750×1060 type: the feed size is 630mm, the adjustment range of the discharge port is 80-180mm, the power is 110-132kw, and the output per hour is 130-330t;

(3) PE-900×1200 type: the feeding particle size is 750mm, the adjustment range of the discharge port is 100-210mm, the power is 110-132kw, and the output per hour is 200-500t.

2. Fine crushing series

(1) PE-250×1000 type: the feed size is 210mm, the adjustment range of the discharge port is 25-60mm, the power is 30kw, and the output per hour is 15-52t;

(2) PE-300×1300 type: the feeding particle size is 260mm, the adjustment range of the discharge port is 30-90mm, the power is 55kw, and the output per hour is 30-70t.

Output is one of the important criteria for measuring the performance of jaw crushers. Although the output of each type of jaw crusher is fixed, operating in accordance with the regulations can increase the output of the equipment within a certain range. Bring greater profits to investment companies.
